These are the microcontrollers implemented in OSIMPLC and can be programmed using LDmicro, Great Cow Basic (and the ATmega1284P using Arduino IDE and Mighty Core plugin). It works very well with PIC16F887 and ATmega1284P.

Power Supply: 16-18Vdc centre positive (not included) or 12Vdc if only flash devices need to be programmed (Order Code 660.I've build a serial (UART-TTL) display for my OSIMPLC (Open Simple Industrial Modular PLC), Open Hardware + Free Software project, see.

Please note that LV programming is not supported. If you only need to program Flash devices please see our AS3150ZIF programmer that requires no external power supply.

Devices Supportedĭevices currently covered by this programmer (when used with the latest version of MicroPro) are listed below.

Software tells you where to place the PIC you are programming. It accepts HEX/Object files and has Program, Verify, Read, Blank Check, OSCAL and Fuse functions. Software is compatible with Windows 3.1 to 10 (32 and 64 bit versions). The price includes our own tailor-made and fully functional MicroBurn software interface which is available for free downloading. The whole package comes at a very competitive price and is supplied fully assembled and tested with a 40 pin wide ZIF socket that allows insertion of 8, 18, 28 and 40 pin devices supported by socket programming. High quality double sided PTH PCB (102 x 78mm). FREE Windows software interface (see below for details).Ħ-pin header cable for ICSP supplied (GND, VCC, CLK, DAT, LOW, VPP1). Auto Program feature for fast no-key-press bulk programming.

Programs a wide range of both Flash and OTP devices. Reliable, high speed, professional quality USB or Serial port Flash PIC® Microcontroller Programmer with programming ZIF socket and 6-pin ICSP connector.
